Fluid Bed Dryer Bags

Fluid Bed Dryer Bags

Fluidized bed technology is used in many applications such as the formulation process in the pharmaceutical industry or the production of fine chemical powders by mixing, agglomeration, granulation, sizing, drying, coating or micronizing.

This machinery requires the bag which ensures that the process is carried smoothly.

  • Our bags are stitched and sealed to ensure minimal loss of particles.
  • Fabrics used with electrical conductivity to reduce risk of explosion.
  • Labelling and Coding provided to trace the product and maintain stock.

FBD /FBP Bag

Media - Antistatic Polypropylene, Antistatic Polyester, Antistatic Multifilament, Antistatic Non-Woven, PC Satin, H Grade Antistatic, etc.

Sizes

3Kg to 600Kg

Type

As per OEM Drawing.

Bonnet Bag

Media

Antistatic Polypropylene, Antistatic Polyester, Antistatic Multifilament, Antistatic Non-Woven, PC Satin, H Grade Antistatic, etc.

Sizes

3Kg to 1500Kg

Type

As per OEM Drawing.

Combo D Type

Media

Antistatic Polypropylene, Antistatic Polyester, Antistatic Multifilament, Antistatic Non-Woven, Bolting Cloth.

Sizes

125Kg to 1500Kg

Type

As per OEM Drawing.

RMG Vent Filter Bag

Media

Antistatic Polypropylene, Antistatic Polyester, Antistatic Multifilament, Antistatic Non-Woven, PC Satin, H Grade Antistatic.

Size & Type

As per OEM drawing/Customer Requirements.

Sr No. Fabrics Air Permability Tensile Strength/ Br Strength Gramage / weight Elongation Temperature
1 Antistatic Polyster - ( Satin Finish ) 4.01 ( ft³ / ft² min ) -@ 310 pa 33 Kgf/cm² 304 gsm 35.7% Warp 32.5%Weft 110° C - 120° C
2 Antistatic ( Polyproplene ) 37.4 ( ft³ / ft² min ) -@ 20 mm wc 46.5 Kgf/cm² 412 gsm 41.7%Warp 31.0 wf %Weft 80° C - 100° C
3 Antistatic polyster Non - Woven ( Needle Punch ) 64.9 ( ft³ / ft² min ) -@ 20 mm wc 55.1 Kgf/cm² 500 - 900 gsm 15% Warp 25% Weft 150° C
4 Epitropic 0.3 to 0.4 ( ft³ / ft² min ) -@ 20 mm wc 150 Kgf/cm² Warp 200 Kgf/cm² Weft 190 - 200 gsm N/A 150° C
5 PC Satin 24 ( ft³ / ft² min ) -@ 20 mm wc 250 Kgf/cm² Warp 160 Kgf/cm² Weft 335 gsm 18% Warp - 15% Weft 110° C - 120° C
6 Polyprpolene ( PP - 101 ) 0.27 ( ft³ / ft² min ) -@ 20 mm wc 235 Kgf/cm² Warp 130 Kgf/cm² Weft 327 gsm N/A 80° C
7 PP Spun 8 ( ft³ / ft² sec min ) -@ 20 mm wc 430 Kgf/cm² Warp 160 Kgf/cm² Weft 450 gsm 25% warp 30% Weft N/A
8 PP Needle Punch - Non Woven 11.48 to 16.40 ( ft³ / ft² min ) -@ 20 mm wc 215 Kgf/cm² Warp 190 Kgf/cm² Weft 700 gsm N/A N/A
9 PP Multifilament 6.07 ( ft³ / ft² min ) -@ 20 mm wc 450 Kgf/cm² Warp 375 Kgf/cm² Weft 420 gsm 38% Warp 28% Weft N/A
10 Polyster ( 550 gsm ) 49.21 ( ft³ / ft² min ) -@ 20 mm wc 160 Kgf/cm² 550 gsm 15% Warp 25% Weft 140° C - 150° C
